Automatic Rain Gauge[ARG-5]

Automatic Rain Gauge[ARG-5]

To Get Product Price Request a Quote
In Stock

Automatic Rain Gauge Station having the industrial grade micro controller datalogger ensure the reliability, accuracy and continuous performance in the toughest weather condition. BHM make Automatic Rain Gauge is the best choice for the research works in the market. Design makes easy to installed by one person and reduce the transportation cost. Automatic Rain Gauge Model BHM-Compact-ARG-5 comes with the tripod stand, solar panel and battery case having the an intelligent solar and AC power circuit which make the system self-powered. 16 X 2 alphanumeric display and 1 X 4 keypad is provided at front of data logger for programming data logger and Rain Gauge sensor reading at site without the help of computer. The lithium on battery having the more than 2 years of life and < 10 days of the backup at no sunlight and extremely hardest weather condition.

  • Category : Rain Gauge
  • Model Number : BHM-Compact-ARG-5
  • Brand : Balaji Hydromet
  • Automatic Rain Gauge[ARG-5]

    Automatic Rain Gauge Station having the industrial grade micro controller datalogger ensure the reliability, accuracy and continuous performance in the toughest weather condition. BHM make Automatic Rain Gauge is the best choice for the research works in the market. Design makes easy to installed by one person and reduce the transportation cost. Automatic Rain Gauge Model BHM-Compact-ARG-5 comes with the tripod stand, solar panel and battery case having the an intelligent solar and AC power circuit which make the system self-powered. 16 X 2 alphanumeric display and 1 X 4 keypad is provided at front of data logger for programming data logger and Rain Gauge sensor reading at site without the help of computer. The lithium on battery having the more than 2 years of life and < 10 days of the backup at no sunlight and extremely hardest weather condition.
  • DATA LOGGER -VIEW

    Model Compact-datalogger version v-21.7
    Display 16 Characters x 2 Lines alphanumeric display (Auto Light on when touch the keypad button)
    Measured Parameter Date, Time, Rainfall (mm), Logger Temperature (°C), Battery(volts)
    Real Time Clock Stability long-term: ±1 ppm / year Stability (temperature): ±3.5 ppm or better form -40° to 85°C
    Logging Rate 1 min to 1 hours
    Data Storage 16 GB (sufficient for more than 5 years of logging in 1 min. (logging rate)
    Logger Power supply 5 volts
    RTC Battery Life < 5 years in continuous operation
    Clock accuracy ±5 seconds per year
    Keypad 1 x 4 on front of the datalogger programming and check the sensors Realtime reading
    Logger Programming Through given keypad in front of the logger
    IP rating IP 65
    Operating Temp. -40°C to 75 °C
    Operation Humidity 0 to 95% no-condensing
    Data Retrieval SD Card and RS 485 (Optional) No need of any software direct copy and past
    Data Transmission GPRS telemetry OR WIFI in IOT (optional)
    Watchdog timer System Reset Upon Microprocessor Failure
    Model BHM-compact-BAT
    Protection Reverse Polarity Battery over Charge Protection Battery over Discharged Protection
    Battery Charging Provided Inbuild solar charging Circuit through Battery management System OR 220 volts AC supply (optional)
    Battery Life More than 2 years
    Battery Voltage & Amp 5 volts and 20 AMP
    Advance Feature Soft Start Charging or good health of battery Battery Temperature measurement inside Disconnect charging when temperature of batter goes high than normal
    Solar Pannel 6 volts 2 Amp
    Output Voltage 5 Volts DC
    Type Tipping Bucket (Self Empty)
    Diameter 5”
    Accuracy of rain gauge 100 mm / hour, better than ± 3 %
    Collection area 127 cm²
    Design Aerocon for remove the wind effect
    Resolution 0.20 mm
    Operating condition 0°C to +70 °C 0...100 %
    Output Switch Encloser
    Material Polycarbonate
    Capacity Unlimited
    Mounting width SS strip at the bottom of the Rain Gauge
  • • Hydrology
    • General rainfall monitoring
    • Rainfall distribution and intensity
    • Remote monitoring
    • Leachate/run-off monitoring
    • Ecological studies
    • Agriculture
    • Climate change studies
    • Classical meteorology and hydrology
    • Agriculture meteorology
    • Measuring networks of water suppliers
    • Lysimeter systems
    • Sewage plants
    • Weather services
    • Airports
  • Ordering Guide

    BHM-compact-Datalogger Datalogger
    BHM-A-SSS Stainless Steel Stand
    BHM-A-SP Solar Panel
    BHM-compact-BAT Battery with charging
    BHM-S-TBRG-5” Tipping Bucket Rain Gauge Sensor
